Dolby® MS11 Multistream Decoder

The Dolby® MS11 Multistream Decoder provides a comprehensive solution for decoding all premium broadcast audio formats for televisions and set-top boxes. These include Dolby Digital Plus, Dolby Digital, HE AAC and all AAC bitstreams. The Dolby® MS11 Multistream Decoder reduces the complexity and cost of integrating multiple audio technologies in new receivers. It also simplifies product development and testing.

The ESPICO implementations are based on the Dolby reference model with proprietary optimisations to reduce memory and MHz requirements. Contact ESPICO for specific resource requirements.

Features

• Fully tested and qualified by Dolby for ZSP800 core
• <100 MCPS for dual decode on ZSP800
• Reduces the cost and complexity of integrating multiple audio technologies in new receivers
• Supplies full Dolby metadata support for Dolby Digital Plus and Dolby Digital formats
• Allows pass-through of the main audio directly for output over HDMI® interfaces

Availability

ESPICO’s optimised solution can be ported to any platform. Platforms supported include:

• ZSP Cores including ZSP400, ZSP500, ZSP800 families
• ARM including Cortex and NeonTM
• MIPS32 74KTM
• Ceva DSP Cores

Applications

• Digital television
• Set top boxes
